Inside the naked frame
The rear end cut off
Rear appron sitting in place

Some rust treatment
Ready for some frame work

Rear engine waiting clean up
Close up of the Isuzu 6BD1 engine
Appron sitting on new rear frame section
About a week into it & door off !!!!

Another angle of rear

Our daughter ready to work !!!!!

Part of the work station

Rear section that we cut off

Too rusted

From rear looking forward

The front end

Drivers side

Large slide out will be in this section

Large 400lt diesel tank fitted

Our son watching dad work

Rust out

Will replace oil cooler & radiator
Apron taken off for full welding and prep

welder, welding, rhs
The welder all set up ready

Some new frame work

All tacked in

Starting to look good again

Window dummy fit

Added some bracing
Rubbish piles up quick

bus, motorhome, rv, rust removal, welding
Top half  of rear
welding, rust treatment, rv, motorhome conversion
All prep and primed in Metalfix
From the inside
The rear side has been welded, prep and primed
Drivers rear taking shape too
One roll of two
Roll of alloy sheet
Removing the air con system
More removal
Still have main unit to remove
prefabricated out riggers and drivers side parts
Insulation to be sandwiched between the walls
Rear window sheeted in
Vents to be installed underneath this sheet
Sheet from the inside view
Protective cover removed
The size of the alloy against the rig

Rv rust removal
Another piece fitted
alloy sheet
A sheet of 4mm a.c.p

Rear engine door fabricated
Sheeting applied
Slide out bed starting to take shape
Sheeting weighted down for firm/flat adhesive

linear bearing, fully supported rail
Linear slide bearings

Slide out bed, Rv, Linear bearing slide, motorhome slide out
Slide out bed base

linear motor
Linear motor to operate the bed

welding linear slide out, Rv slide out, electric slide out, motorhome slide
A few more welds needed

Temp fitment of locks

View of completed engine door

gas struts, motorhome, rv
Gas struts fitted

Test fit and alignment

Tested with a couple of rivets

Close up once finished

led rear lights, motorhome, rv
Fitment of top rear lights
